Yuxi paint bucket shredder machine is new type energy-saving and environmentally friendly metal bucket shredding machine, used to shred paint buckets and other metals to realize the recycling and reuse of resources. Yuxi paint bucket shredding machine is composed of motor, reducer, rotating cutter shaft, movable cutter, fixed cutter, frame, base, cabinet and other structures. Yuxi metal bucket shredder for sale is advanced shredding equipment integrating advantages of all shredder machine and crushing machine.
Application of Paint Bucket Shredding Machine
1. Plastic buckets, plastic bottles.
2. Metal cans, paint buckets, metal barrels.
3. Tires, car bumpers, roadblocks, circuit boards.
4. Scarp appliances such as washing machines and refrigerators.
5. Domestic garbage, paper mill waste.
Foundry Technology of Metal Bucket Shredder Machine
1. The cutters of metal bucket shredder is made of special alloy steel (high-speed steel or tool steel), with a hardness above HRC60 after heat treatment, so they have long service life, strong cutting ability and high productivity.
2. The cutters of paint bucket shredder machine are arranged in a spiral line to realize efficient cutting.
3. Both the inner hole of cutters and the spindle surface adopt a hexagonal design to realize the uniform force of cutter.
4. The split box design helps remove the entire cutter shaft (shaft, blade, bearing, sealing system) easily and quickly.
Yuxi metal bucket shredding machine can be equipped with conveyor belt, two-stage crusher, steel wire separator, nylon separator, and pulverizer. Feel free to contact us, thank you.
Parameter of Paint Bucket Shredder
Models
Power (Kw)
Capacity
Materials size
Hopper size
Weight
Dimension
YXS-600
15*2KW
2-3T/H
3-10CM
0.82*0.9M
2.5T
2.6*2*1.9M
YXS-800
22*2KW
3-5T/H
3-10CM
0.9*1.0M
3.6T
2.8*2*1.9M
YXS-1000
37*2KW
5-8T/H
3-10CM
1.2*1.0M
5.7T
3*2*1.9M
YXS-1200
45*2KW
6-10T/H
3-10CM
1.4*1.0M
9.5T
3.2*2*1.9M
YXS-1400
55*2KW
8-12T/H
3-10CM
2.0*2.0M
18T
4.3*2*2.4M
YXS-1600
75*2KW
12-18T/H
3-10CM
2.3*2.0M
24T
5*3*2.4M
YXS-2000
90*2KW
16-22T/H
3-10CM
2.3*2.0M
35T
6*3.5*2.4M
YXS-2200
132*2KW
20-26T/H
3-10CM
2.5*1.8
62T
7*4*4.5m
YXS-2600
160*2KW
25-60T/H
3-10CM
3.2*2.0
85T
8.2*4*4.3m
Please leave a message for your requirements, the machine can be customized for you.
